# What Is TrueConf Group?

# Endpoint Purpose

TrueConf Group video conferencing terminals are an integrated software and hardware solution designed for small, medium, and large meeting rooms. The terminal lineup includes models such as TrueConf Group and TrueConf Group Silent.

More about TrueConf Group

With this terminal, you can deploy a ready-to-use system for organizing video communication using SIP, H.323, RTSP, VNC, and NDI protocols. Depending on the configuration, it supports video communication up to 2160p quality and can function as an MCU with up to 12 ports.

With TrueConf Group, you can:

  • Make video calls

  • Organize video conferences (if built-in MCU is enabled)

  • Record video meetings

  • Capture and share content from USB devices and video capture cards

  • Stream conferences to third-party platforms

  • Connect NDI and VNC video sources

  • control the terminal using a pre-configured touch tablet with special firmware (this tablet is included in some supplied kits);

  • manage the terminal through the web interface from a browser (available to administrators only);

  • Use additional features when integrating with TrueConf Server and TrueConf MCU

  • work with two monitors simultaneously;

  • display the presentation and other content on an additional screen.

Thanks to modular configuration, TrueConf Group is compatible with a number of peripheral devices:

  • compatible PTZ cameras that operate via USB 2.0/USB 3.0/HDMI interfaces and support control via RS-232 (VISCA, Pelco-P, Pelco-D) or USB;

  • USB speakerphones

  • a desktop tablet for terminal management;

  • Analog playback or audio capture devices

  • monitors connected via HDMI and DisplayPort.

Example of connecting peripheral equipment for TrueConf Group:

/docs/group/media/connection_scheme/en.png

Example of connecting peripheral equipment for TrueConf Group Silent:

/docs/group/media/connection_scheme_silent/en.png

Our managers will be happy to provide you with a free consultation about the TrueConf Group kit that suits your needs best. Please contact our sales department to learn more.

# Configuration

TrueConf Group comes in different kits that may include:

  • Video conferencing endpoint (with an optional built-in MCU)

  • Built-in capture card with two HDMI inputs (optional)

  • Remote control

  • AV peripherals (e.g., PTZ camera and speakerphone).

# General Description

TrueConf Group and TrueConf Group Silent terminals are devices encased in a metal body. An infrared receiver for the remote control is located behind the decorative plastic front panel.

Ports on the rear panel of the TrueConf Group:

/docs/group/media/tcg_back/en.png

Connectors on the rear panel of TrueConf Group Silent:

/docs/group/media/tcgs_back/en.png

  1. RS-232 to control PTZ camera

  2. HDMI inputs to capture content or connect HDMI cameras (depends on your kit)

  3. Power connector

  4. HDMI output to connect the main screen

  5. DisplayPort to connect an additional screen

  6. USB 2.0 to connect AV peripherals

  7. RJ-45 for Ethernet connection

  8. USB 3.1 to connect AV peripherals

  9. Additional audio output to connect an audio output device

  10. Additional audio input to connect an analog microphone
